Vehicle Lifts & Lifting Equipment · SHL-Y-J-40CBL PRO750-800
Ultrathin Small-Platform Scissor Lift 4000 kg, Double-Level
A double-level scissor lift with a closed height of just 110 mm, rated at 4000 kg with an 1880 mm lift height. The low closed height lets low vehicles drive on without extra ramps.
Overview
This model in three numbers
Key Features
What the standard supply includes
- 110 mm closed height
- Double-level structure
- CNC laser-cut frame
- Powder-coated frame
- German / Italian oil seals
- Italian technology — per the supplier sheet
Engineering basis
What makes the difference day to day
110 mm closed height
A 110 mm closed height lets low vehicles drive straight onto the platform, removing the need for extra ramps that eat into bay space.
Powder-coat finish
Powder coating gives the frame a bonded surface that stands up to the oils and solvents landing on a lift platform every day, where liquid paint would flake and let rust start underneath.
Specifications
SHL-Y-J-40CBL PRO750-800 specification table
| Specification | Value |
|---|---|
| Lifting capacity (kg) | 4000 |
| Lift height (mm) | 1880 |
| Closed height (mm) | 110 |
| Platform (mm) | 1530–2140 × 665 |
| Motor power (kW) | 3 |
| Voltage | 220 V 1ph 60 Hz |
| Structure | Double level |
| Fabrication | CNC laser cut, powder coat |
How it differs
How the SHL-Y-J-40CBL PRO750-800 differs from its closest model
This model shares its 1880 mm lift height, double-level structure and surface treatment with the 4500 kg version.
Three differences are measured: capacity 4000 kg against 4500, closed height 110 mm against 135, and platform width 665 mm against 720.
This one takes lower vehicles; that one carries more weight.
Industries
Sectors this model serves
These are the industries the SHL-Y-J-40CBL PRO750-800 serves specifically, not the family as a whole.
FAQ
Frequently asked about the SHL-Y-J-40CBL PRO750-800
What is the closed height?
110 mm, so low vehicles drive on without extra ramps.
What are the capacity and lift height?
4000 kg capacity and 1880 mm lift height.
How is the frame treated?
Powder-coated over a CNC laser-cut frame.
How does it differ from the 4500 kg model?
In three measured ways: 4000 kg against 4500, 110 mm closed height against 135, and 665 mm platform width against 720.
Request a quote for the Ultrathin Small-Platform Scissor Lift 4000 kg
Tell us your sector and bay size in the form, and the quote comes back built around the configuration your site needs, not a generic one.
