Vehicle Lifts & Lifting Equipment · SHL-2-245C-3700
Clear-Floor Two-Post Lift 3700 mm for Daily Service Bays
A two-post lift with a completely obstruction-free floor, rated at 4500 kg with a 1990 mm lift height. The compact version of the range, for bays where the technician walks under the vehicle without a floor beam.
Overview
This model in three numbers
Key Features
What the standard supply includes
- Compact version of the two-post range
- Direct cylinder drive, no chain
- Polymer slider on the column
- Toothed ratchet arm locks
- Overhead gate frame, nothing across the floor
- Roof protection
- 50 s rise, 30 s descend
Engineering basis
What makes the difference day to day
Direct drive, no chain
The hydraulic cylinder drives the carriage directly without a chain, so there is no chain in the lift path to inspect or re-tension.
Polymer slider
A polymer slider running in the column track needs no periodic greasing and does not score the track, cutting column maintenance and keeping travel quiet across thousands of cycles.
Specifications
SHL-2-245C-3700 specification table
| Specification | Value |
|---|---|
| Lifting capacity (kg) | 4500 |
| Lift height (mm) | 1990 |
| Motor power (kW) | 2.2 |
| Voltage | 380 V / 220 V |
| Rise / descend time (s) | 50 / 30 |
| Structure type | Overhead gate — clear floor |
| Drive | Direct cylinder drive — no chain |
| Arm locking | Automatic toothed ratchet |
| Protection | Roof protection |
How it differs
How the SHL-2-245C-3700 differs from its closest model
This model shares its rated capacity (4500 kg), lift height (1990 mm), motor power (2.2 kW) and rise/descend times with the 3900 mm version.
The difference is configuration: this is the compact version, its cylinder driving the carriage directly without a chain, while the 3900 mm model uses a twin-cylinder chain drive with steel-wire synchronisation. Both have toothed ratchet arm locks.
Industries
Sectors this model serves
These are the industries the SHL-2-245C-3700 serves specifically, not the family as a whole.
FAQ
Frequently asked about the SHL-2-245C-3700
What is the rated lifting capacity?
The rated capacity is 4500 kg with a 1990 mm lift height, as listed on the specification sheet at standard configuration.
How long does a full cycle take?
Rise takes 50 seconds and descend 30 seconds.
What power supply does it need?
A 2.2 kW motor on either 380 V or 220 V, depending on the configuration ordered.
How does it differ from the 3900 mm model?
Capacity, height, power and cycle times are identical. This is the compact version with a direct drive and no chain; the 3900 mm model uses a twin-cylinder chain drive with steel-wire synchronisation. Both have ratchet arm locks.
