Vehicle Lifts & Lifting Equipment · SHL-Y-J-40B
Small-Platform Scissor Lift 4000 kg with Hydraulic Balancing
A small-platform scissor lift with a 1999 mm lift height — the highest in the family — rated at 4000 kg. Its platform extends from 1560 to 1760 mm to suit different wheelbases.
Overview
This model in three numbers
Key Features
What the standard supply includes
- Hydraulic balancing between platform sides
- Adjustable platform length 1560-1760 mm
- Japanese / Italian oil seals
- Italian technology — per the supplier sheet
Engineering basis
What makes the difference day to day
Hydraulic balancing
Hydraulic balancing holds both platform sides at the same height under load, so the vehicle sits stable and the technician works on a level surface rather than a tilted one.
Adjustable platform length
Setting platform length between 1560 and 1760 mm lets one unit serve different wheelbases instead of being fixed to a single size.
Specifications
SHL-Y-J-40B specification table
| Specification | Value |
|---|---|
| Lifting capacity (kg) | 4000 |
| Lift height (mm) | 1999 |
| Platform (mm) | 1560–1760 × 565 |
| Motor power (kW) | 3 |
| Voltage | 220 V 1ph 60 Hz |
| Balancing | Hydraulic |
| Oil seals | Japanese / Italian |
How it differs
How the SHL-Y-J-40B differs from its closest model
Its 1999 mm lift height is the highest in the family, against 1880 mm on the ultrathin small-platform models, 1220 mm on the movable unit and 600 mm on the ultrathin mid-rise.
Its platform is also the narrowest of the small-platform models at 565 mm, against 665 and 720 mm.
Industries
Sectors this model serves
These are the industries the SHL-Y-J-40B serves specifically, not the family as a whole.
FAQ
Frequently asked about the SHL-Y-J-40B
What is the lift height?
1999 mm, the highest of this family’s models.
Is the platform length adjustable?
Yes — from 1560 to 1760 mm, to suit different wheelbases.
How is the platform kept level?
By hydraulic balancing that holds both sides at the same height under load.
What power supply does it need?
A 3 kW motor on 220 V single-phase at 60 Hz.
